Writing efficient Emacs modeline segments

Build your own powerful modeline segments!

Ellis Kenyő

29th July 2025

8 min read

Writing complex segments can seem performance intensive; but we can work on that

Your editor’s status bar could be telling you everything you need to know, or it could be telling you nothing useful at all.

This contrast captures a fundamental difference in philosophy. One approach says “show everything always”—file trees, git status, diagnostics, system info, all fighting for attention whether you need them or not. The other says “show what matters when it matters.”

I’m firmly in the second camp. When I’m reading a PDF, I want page numbers—not git blame info. When I’m debugging a deployment, I want CI status—not my music player. When I’m deep in a coding flow, I want just enough information to stay oriented without visual noise breaking my concentration.

This is where Emacs truly shines. While other editors bolt on features through plugins that may or may not cooperate, Emacs gives you the primitives to build exactly the interface you want. Need to see deployment status while working on a hotfix? Trivial. Want weather info when deciding whether to bike to work? Built in minutes. Current song while you code? Why not.

The magic happens in the modeline—that thin strip at the bottom that most people ignore. In Emacs, it becomes a contextual dashboard that adapts to what you’re actually doing. But here’s the catch: building these powerful, live-updating segments naively will bring your editor to its knees…

Building a simple modeline segment

Let’s start by building the “wrong” way first—a naive implementation that demonstrates exactly why this is tricky. We’ll create a simple weather widget using wttr.in that updates live in your modeline.

For simplicity, we’ll just worry about the one-line output version.

;; Define a variable that mode-line-format will call
;; :eval means evaluate the form and return the value in-place
(setq-default my/wtter-status
  '(:eval
    (when (mode-line-window-selected-p)
      (propertize  (with-current-buffer (url-retrieve-synchronously "https://wttr.in/London?format=3")
                    (set-buffer-multibyte t)
                    (goto-char (point-min))
                    (re-search-forward "^$" nil 'move)
                    (forward-char 1)
                    (string-trim-right
                     (decode-coding-string
                      (buffer-substring-no-properties (point) (point-max))
                      'utf-8)))
                  'face 'doom-modeline))))

;; Needed so Emacs knows it can evaluate it safely
(put 'my/wtter-status 'risky-local-variable t)

;; Default modeline (evaluate this to fix)
(setq-default mode-line-format
              '("%e" mode-line-front-space
                (:propertize
                 ("" mode-line-mule-info mode-line-client mode-line-modified
                  mode-line-remote)
                 display (min-width (5.0)))
                mode-line-frame-identification mode-line-buffer-identification "   "
                mode-line-position (vc-mode vc-mode) "  " mode-line-modes
                mode-line-misc-info mode-line-end-spaces))

;; Our custom one
(setq-default mode-line-format
              '("%e" mode-line-front-space
                (:propertize
                 ("" mode-line-mule-info mode-line-client mode-line-modified
                  mode-line-remote)
                 display (min-width (5.0)))
                mode-line-frame-identification mode-line-buffer-identification "   "
                mode-line-position (vc-mode vc-mode) "  " mode-line-modes
                mode-line-misc-info my/wttr-status mode-line-end-spaces))

;; If you have issues with the modeline now showing the new status
(kill-local-variable 'mode-line-format)

Great! Job done, how easy!?

Well … not quite. If you tried to evaluate that blindly without reading the slightly spoiler-y comments, this brings Emacs to its knees. Every time the modeline wants to update, it’s calling out to wttr.in. There’s a lot of triggers that cause the modeline to update, so you likely had constant pauses and freezes.

But you promised we can make them fast?

I did! The problem is clear: we’re making synchronous network calls every time Emacs wants to refresh the display. That’s like stopping to call your friend for the weather update every time you glance at your phone.

So let’s see what we can do.

Making things better

Okay so right away you should be able to spot the issue, we’re calling synchronously to a service and blocking every time.

For some things, this can be ideal for example if you need the result and you won’t do any other operations in the meantime. But unless you want to use Emacs as an interface to wttr.in, you’ll probably want to use it for other things too. So thanks to the async nature of url-retrieve, we can shift the burden of this processing to a thread and shift the current model of how we handle this.

Let’s get into the weeds a bit here

Pub/Sub

So what we’re doing currently works just fine for simple data, that’s how the default Emacs modeline segments work. I encourage you to check them out, all the symbols in the above mode-line-format variable are variables themselves, so have a look in C-h v mode-line-. Most of the time we’re just taking the value of other variables and formatting them nicely.

However when there’s complex processing or even an external service to consider, we have to change the model from “run this function constantly” to instead do “format this variable constantly”. That would be ideal, wouldn’t it?

A partial solution we could do here is using a future, we could lean on that part of emacs-async and have the processing work like that. That’ll work right?

Well … not quite. The problem is that the modeline still calls our function constantly—it’s just that now each call creates a new future. So instead of one blocking call, you get dozens of pending network requests stacking up, as the diagram below demonstrates.

Unresolved futures diagram

As time goes on, more futures are being created but they don’t ever properly resolve.

Instead of “run this code every time the modeline refreshes,” we want “update this variable occasionally, and let the modeline just display it.” Think of it like the difference between asking someone the time every few seconds versus glancing at a clock that updates itself.

This is where the idea of pub/sub comes in.

Short for “publisher/subscriber”, it describes a relationship between two services (in the sense of long-running processes) in which one pushes data out and one or many other services listen out for updates.

Think of it like a newspaper delivery model: instead of you walking to the newsstand every time you want to check headlines (the blocking approach), the newspaper gets delivered to your door once a day and you just read whatever’s there when you want it (the pub/sub approach). The “publisher” (weather service) does its work on its own schedule, and the “subscriber” (your modeline) just displays whatever the latest data is.

Thanks to the asynchronous bits of url-retrieve, we can perform a crude implementation of this¹.

Here’s how it works in practice: we’ll set up a background timer that fetches weather data every few seconds and stores it in a simple variable. The modeline will just display that variable’s contents—no network calls, no blocking, just fast text formatting.

Let’s build it.

;; Define this first to appease the byte-compiler gods
(setq-default my/wttr-status-text "")
(put 'my/wttr-status-text 'risky-local-variable t)

;; Define an async callback with url-retrieve
(defun my/wttr-update ()
  "Update the current wttr status asynchronously."
  (message "Updating wttr.in")
  (let ((url-show-status nil))
    (url-retrieve "https://wttr.in/London?format=%l:%20%C+%t&q"
                  (lambda (status)
                    (if (plist-get status :error)
                        (message "Failed to fetch weather: %s" (plist-get status :error))
                      (progn
                        (set-buffer-multibyte t)
                        (goto-char (point-min))
                        (re-search-forward "^$" nil 'move)
                        (forward-char 1)
                        (setq my/wttr-status-text
                              (string-trim-right
                               (decode-coding-string
                                (buffer-substring-no-properties (point) (point-max))
                                'utf-8)))
                        (force-mode-line-update)
                        (message "Weather updated: %s" my/wttr-status-text)))
                    (kill-buffer)))))

;; Define a global timer we can start/stop
(defvar my/wttr--timer nil)
(defun my/wttr-timer ()
  "Start/stop the timer to update wttr status."
  (if (timerp my/wttr--timer)
      (cancel-timer my/wttr--timer)
    (setq my/wttr--timer
          (run-with-timer
           1                 ;; Delay for the first run
           5                 ;; How often in seconds to run after the first
           #'my/wttr-update ;; The function to call
           ))))

;; Our custom modeline using our new text variable
(setq-default mode-line-format
              '("%e" mode-line-front-space
                (:propertize
                 ("" mode-line-mule-info mode-line-client mode-line-modified
                  mode-line-remote)
                 display (min-width (5.0)))
                mode-line-frame-identification mode-line-buffer-identification "   "
                mode-line-position (vc-mode vc-mode) "  " mode-line-modes
                mode-line-misc-info my/wttr-status-text mode-line-end-spaces))

;; If you have issues with the modeline now showing the new status
(kill-local-variable 'mode-line-format)

Much nicer! I’ve added an annoying “Updating” message so you can see how often it’s really updating (spoiler alert: often) and yet, no impact on the editor!

url-retrieve runs the request asynchronously and upon getting the result, will run the specified callback on the buffer. The buffer we get back has the entire response including HTTP headers, which is why we have to skip to the first blank line to get the response. Here all our callback does is simply set the value, trigger a modeline update to ensure that it is always up to date then print another message to say it’s done (this is purely for our demo purposes).

We supplement this with a simple timer to call our update class every 5 seconds and an easy way to disable the timer on the fly.

Where to go from here

This pattern—background updates with variable binding—works for any external data source you want in your modeline. CI/CD status, music players, system monitoring, you name it.

Tools and Extensions

I use doom-modeline myself, which has a nice API for defining segments: https://github.com/seagle0128/doom-modeline
For split-style modelines, check out mode-line-format-right-align
Here’s a real-world example using this pattern: https://github.com/elken/doom-modeline-now-playing (you can find the old implementation here)
For more complex needs, there is emacs-async which spins up an instance of Emacs that can use around 60-100MB of RAM, so this isn’t advised for very simple operations like this that have alternatives²
